Yamaha Stratoliner
- Production years
- 2009–2010
- Brand
- Yamaha
1 / 10
YAMAHA Stratoliner (2008-2009)
Selected year: 2010
Technical specifications
- Engine capacity
- 1,854 cm³
- Wet weight
- 369 kg
- Seat height
- 706 mm
Overview
The Yamaha Stratoliner is a cruiser produced for the 2010 model year. Its air-cooled 48-degree V-twin displaces 1854 cm³ and uses electronic fuel injection; it weighs 369 kg.
A 706 mm seat height gives the bike a low seating position, but its 369 kg weight can make slow-speed maneuvers more demanding. The 155 mm ground clearance leaves limited room over tall obstacles, while the belt final drive avoids chain cleaning and adjustment. The 17 L fuel tank holds a set amount of fuel, but no range estimate can be made without fuel-consumption information.
Specifications
Engine
Engine
- Engine capacity
- 1,854 cm³
- Compression ratio
- 9.5:1
- Stroke
- 99 mm
Performance and transmission
Performance and transmission
- Clutch
- Wet multi-plate
- Final drive
- Belt
- Gearbox
- Manual 5-speed
Dimensions and weight
Dimensions and weight
- Fuel capacity
- 17 L
- Ground clearance
- 155 mm
- Overall length
- 2,581 mm
- Overall width
- 1,054 mm
- Seat height
- 706 mm
- Wet weight
- 369 kg
- Wheelbase
- 1,715 mm
Chassis and suspension
Chassis and suspension
- Frame
- Aluminium
Pros and cons
Advantages
Belt final drive
The belt drive does not need the regular cleaning and adjustment required by a chain.
Low seat
At 706 mm, the seat height can make it easier for many riders to put their feet down at a stop.
Electronic fuel injection
Electronic fuel injection meters fuel without requiring the rider to use a manual choke.
Things to consider
Heavy at low speed
At 369 kg, the Stratoliner takes more effort to maneuver at walking pace or when parking.
Limited ground clearance
The 155 mm ground clearance leaves less room over tall bumps and obstacles.
Rider fit
Rider fit calculator
Calculated in your browser
Don't know it? Leave this empty and we'll estimate it from your height.
Estimated from your height: 79 cm
How to measure
Stand barefoot with your back to a wall. Hold a book firmly between your legs, then measure from the floor to the top edge of the book.
Estimated ground reach
Both feet likely flat
You should have a stable stance at a stop, although seat width and suspension setup still matter.
Seat height
706 mm
Approx. loaded height
676 mm
Estimate assumes about 30 mm of suspension sag. Seat width, footwear, luggage and suspension settings can change real reach. Always sit on the motorcycle before buying.
Fuel range calculator
Enter your expected fuel consumption to estimate the distance on a full tank, with or without a fuel reserve.
Tank 17 L at 5.5 L/100 km
Lower consumption = longer range.
Estimated range
309 km
With 10% reserve
278 km
This is a planning estimate, not a measured result. Speed, route, weather, load and riding style can change real consumption.
FAQ
What engine does the 2010 Yamaha Stratoliner have?
It has an air-cooled 48-degree V-twin engine with a displacement of 1854 cm³ and electronic fuel injection.
What is the seat height of the 2010 Yamaha Stratoliner?
The seat height is 706 mm.
Does the 2010 Yamaha Stratoliner use a chain or belt drive?
It uses a belt final drive.
How much does the 2010 Yamaha Stratoliner weigh?
Its weight is 369 kg.
