Yamaha XV RAIDER CUSTOM
- Production years
- 2008–2012
- Brand
- Yamaha
1 / 3
YAMAHA XV1900 Custom Raider (2008-2009)
Selected year: 2012
Technical specifications
- Engine capacity
- 1,854 cm³
- Wet weight
- 343 kg
- Seat height
- 734 mm
Overview
The 2012 Yamaha XV RAIDER CUSTOM is a cruiser from the XV family, produced in 2012. Its air-cooled, four-stroke V-twin displaces 1854 cm³ and makes 168 Nm of torque at 2500 rpm; it weighs 343 kg.
That torque arrives at low engine speed, giving the V-twin a relaxed, low-rev character. The 734 mm seat height can make stopping and putting a foot down easier, while the 343 kg weight calls for more effort when maneuvering slowly. A belt final drive avoids chain cleaning and adjustment, and the rear suspension is adjustable; the fuel tank holds 15.9 L.
Specifications
Engine
Engine
- Engine capacity
- 1,854 cm³
- Compression ratio
- 9.5:1
- Fuel system
- Electronic fuel injection
- Stroke
- 99 mm
Performance and transmission
Performance and transmission
- Torque
- 168 Nm at 2,500 rpm
- Final drive
- Belt
- Gearbox
- Manual 5-speed
Dimensions and weight
Dimensions and weight
- Fuel capacity
- 15.9 L
- Ground clearance
- 145 mm
- Overall length
- 2,583 mm
- Overall width
- 935 mm
- Seat height
- 734 mm
- Wet weight
- 343 kg
- Wheelbase
- 1,664 mm
Chassis and suspension
Chassis and suspension
- Front suspension
- Telescopic fork
Brakes and wheels
Brakes and wheels
- Front tyre
- 12/70-21
Pros and cons
Advantages
Low-rev torque
The 168 Nm peak at 2500 rpm gives the engine strong pulling force without needing high revs.
Belt final drive
The belt avoids the routine cleaning and adjustment required by a chain.
Adjustable rear suspension
The adjustable Monocross rear suspension lets riders tune the setup to suit their preferences.
Things to consider
Heavy at low speed
At 343 kg, the motorcycle takes considerable effort to maneuver around a parking spot or at walking pace.
Rider fit
Rider fit calculator
Calculated in your browser
Don't know it? Leave this empty and we'll estimate it from your height.
Estimated from your height: 79 cm
How to measure
Stand barefoot with your back to a wall. Hold a book firmly between your legs, then measure from the floor to the top edge of the book.
Estimated ground reach
Both feet likely flat
You should have a stable stance at a stop, although seat width and suspension setup still matter.
Seat height
734 mm
Approx. loaded height
704 mm
Estimate assumes about 30 mm of suspension sag. Seat width, footwear, luggage and suspension settings can change real reach. Always sit on the motorcycle before buying.
Fuel range calculator
Enter your expected fuel consumption to estimate the distance on a full tank, with or without a fuel reserve.
Tank 15.9 L at 5.5 L/100 km
Lower consumption = longer range.
Estimated range
289 km
With 10% reserve
260 km
This is a planning estimate, not a measured result. Speed, route, weather, load and riding style can change real consumption.
FAQ
What is the engine displacement of the 2012 Yamaha XV RAIDER CUSTOM?
It has an 1854 cm³, air-cooled, four-stroke V-twin engine.
How much torque does the Yamaha XV RAIDER CUSTOM produce?
It produces 168 Nm at 2500 rpm.
How much does the 2012 Yamaha XV RAIDER CUSTOM weigh?
It weighs 343 kg.
What is the seat height and fuel capacity?
The seat is 734 mm high, and the fuel tank holds 15.9 L.
