Honda VT1300CX Fury ABS
- Production years
- 2009–2010
- Brand
- Honda
1 / 3
Selected year: 2010
Technical specifications
- Engine capacity
- 1,312 cm³
- Wet weight
- 309 kg
- Seat height
- 683 mm
Overview
The Honda VT1300CX Fury ABS is a cruiser from the 2010 model year. Its liquid-cooled 1,312 cm³ 52-degree V-twin uses a SOHC pushrod layout with three valves per cylinder; it produces 107 Nm of torque at 2,250 rpm and weighs 309 kg.
The 683 mm seat puts the rider low, while the 1,806 mm wheelbase and 309 kg curb weight can make tight, slow-speed maneuvering more demanding. The shaft final drive needs no chain cleaning or adjustment, and the rear shock offers rebound damping and five-position preload adjustment for tailoring the suspension to load and road conditions.
Specifications
Engine
Engine
- Engine capacity
- 1,312 cm³
- Compression ratio
- 9.2:1
- Stroke
- 89 mm
Performance and transmission
Performance and transmission
- Torque
- 107 Nm at 2,250 rpm
- Clutch
- Wet multi-plate, manual
- Final drive
- Shaft
Dimensions and weight
Dimensions and weight
- Fuel capacity
- 12.9 L
- Seat height
- 683 mm
- Wet weight
- 309 kg
- Wheelbase
- 1,806 mm
Chassis and suspension
Chassis and suspension
- Frame
- Steel
Brakes and wheels
Brakes and wheels
- Front tyre
- 90/90-21
- Rear tyre
- 200/50-18
Pros and cons
Advantages
Low seat
At 683 mm, the seat can make it easier for shorter riders to get their feet down at stops.
Shaft final drive
The shaft drive avoids the routine cleaning and adjustment required by a chain.
Adjustable rear suspension
Rebound damping and five-position preload adjustment let riders tune the rear shock for load and road conditions.
Things to consider
Heavy at low speed
At 309 kg, the Fury can take more effort to balance and maneuver in tight spaces.
Long wheelbase
The 1,806 mm wheelbase can make tight turns and parking-lot maneuvers less nimble.
Rider fit
Rider fit calculator
Calculated in your browser
Don't know it? Leave this empty and we'll estimate it from your height.
Estimated from your height: 79 cm
How to measure
Stand barefoot with your back to a wall. Hold a book firmly between your legs, then measure from the floor to the top edge of the book.
Estimated ground reach
Both feet likely flat
You should have a stable stance at a stop, although seat width and suspension setup still matter.
Seat height
683 mm
Approx. loaded height
653 mm
Estimate assumes about 30 mm of suspension sag. Seat width, footwear, luggage and suspension settings can change real reach. Always sit on the motorcycle before buying.
Fuel range calculator
Enter your expected fuel consumption to estimate the distance on a full tank, with or without a fuel reserve.
Tank 12.9 L at 5.5 L/100 km
Lower consumption = longer range.
Estimated range
235 km
With 10% reserve
211 km
This is a planning estimate, not a measured result. Speed, route, weather, load and riding style can change real consumption.
FAQ
What is the engine displacement of the 2010 Honda VT1300CX Fury ABS?
It has a 1,312 cm³ liquid-cooled 52-degree V-twin engine.
How much torque does the Honda VT1300CX Fury ABS produce?
It produces 107 Nm at 2,250 rpm.
What final drive does the Honda VT1300CX Fury ABS use?
It uses a shaft final drive.
How tall is the seat on the 2010 Honda VT1300CX Fury ABS?
The seat height is 683 mm.
