Yamaha X-MAX 125 ABS Business
- Production years
- 2011–2013
- Brand
- Yamaha
Choose model year
1 / 8
YAMAHA X-MAX 125 ABS Business (2012-2013)
Selected year: 2013
Technical specifications
- Engine capacity
- 124.7 cm³
- Power
- 14 hp (10 kW) at 8,750 rpm
- Wet weight
- 176 kg
- Seat height
- 775 mm
Overview
The Yamaha X-MAX 125 ABS Business is a scooter from the 2011–2013 model family. The 2013 version has a liquid-cooled, fuel-injected 124.7 cm³ single-cylinder four-stroke engine producing 14 hp (10 kW) and 11.3 Nm of torque at 8,750 rpm; its wet weight is 176 kg.
Its 775 mm seat height is 17 mm lower than the 2012 model’s, which can make reaching the ground easier. The automatic transmission and belt final drive keep riding simple, while ABS works on both disc brakes. Underseat storage fits two full-face helmets, with a glove box and top case also available; 135 mm of ground clearance leaves less room for tall obstacles.
Specifications
Engine
Engine
- Bore x stroke
- 52.0 x 58.6 mm
- Engine capacity
- 124.7 cm³
- Compression ratio
- 11.2:1
- Cooling system
- Liquid
- Engine type
- Single, four-stroke
- Fuel system
- Injection
- Ignition
- TCI
- Lubrication system
- Wet sump
- Starting
- Electric
Performance and transmission
Performance and transmission
- Power
- 14 hp (10 kW) at 8,750 rpm
- Power weight ratio
- 0.0869 HP/kg (dry)
- Torque
- 11.3 Nm at 8,750 rpm
- Final drive
- Belt
- Transmission type
- Automatic
Dimensions and weight
Dimensions and weight
- Carrying capacity
- Underseat storage for two full-face helmets, glove box, top case
- Dry weight
- 160 kg
- Fuel capacity
- 11.8 L
- Ground clearance
- 135 mm
- Overall height
- 1,337 mm
- Overall length
- 2,220 mm
- Overall width
- 776 mm
- Seat height
- 775 mm
- Wet weight
- 176 kg
- Wheelbase
- 1,545 mm
Chassis and suspension
Chassis and suspension
- Front suspension
- Telescopic fork
- Front wheel travel
- 110 mm
- Rear suspension
- Unit swing
- Rear wheel travel
- 95 mm
Brakes and wheels
Brakes and wheels
- Abs
- Yes
- Front brakes
- Single disc. ABS
- Front brakes diameter
- 267 mm
- Front tyre
- 120/70-15
- Rear brakes
- Single disc. ABS
- Rear brakes diameter
- 240 mm
- Rear tyre
- 140/70-14
Colours and equipment
Colours and equipment
- Colours
- Classy stone (grey)
Model years
2013
Seat height: 792 mm → 775 mm
| Specification | |||
|---|---|---|---|
| Engine capacity | 124.7 cm³ | 124.7 cm³ | 124.7 cm³ |
| Power | 14 hp (10 kW) | 14 hp (10 kW) | 14 hp (10 kW) |
| Torque | 11.3 Nm | 11.3 Nm | 11.3 Nm |
| Wet weight | 176 kg | 176 kg | 176 kg |
| Seat height | 792 mm | 792 mm | 775 mm |
| Fuel capacity | 11.8 L | 11.8 L | 11.8 L |
Pros and cons
Advantages
ABS on both wheels
The front and rear ABS can help prevent wheel lockup during hard braking.
Helmet-sized storage
The underseat compartment can hold two full-face helmets, reducing the need to carry them separately.
Lower 2013 seat
At 775 mm, the seat is lower than the 2012 version, helping riders reach the ground more easily.
Things to consider
Limited ground clearance
The 135 mm clearance leaves less room over tall bumps and uneven surfaces.
Rider fit
Rider fit calculator
Calculated in your browser
Don't know it? Leave this empty and we'll estimate it from your height.
Estimated from your height: 79 cm
How to measure
Stand barefoot with your back to a wall. Hold a book firmly between your legs, then measure from the floor to the top edge of the book.
Estimated ground reach
Both feet likely flat
You should have a stable stance at a stop, although seat width and suspension setup still matter.
Seat height
775 mm
Approx. loaded height
745 mm
Estimate assumes about 30 mm of suspension sag. Seat width, footwear, luggage and suspension settings can change real reach. Always sit on the motorcycle before buying.
Fuel range calculator
Enter your expected fuel consumption to estimate the distance on a full tank, with or without a fuel reserve.
Tank 11.8 L at 3.5 L/100 km
Lower consumption = longer range.
Estimated range
337 km
With 10% reserve
303 km
This is a planning estimate, not a measured result. Speed, route, weather, load and riding style can change real consumption.
FAQ
What engine does the 2013 Yamaha X-MAX 125 ABS Business have?
It has a liquid-cooled, fuel-injected 124.7 cm³ single-cylinder four-stroke engine producing 14 hp (10 kW) and 11.3 Nm at 8,750 rpm.
Does the Yamaha X-MAX 125 ABS Business have automatic transmission?
Yes, it has an automatic transmission and belt final drive.
What is the seat height, and did it change for 2013?
The 2013 seat height is 775 mm, down from 792 mm in 2012.
How much storage does the X-MAX 125 ABS Business have?
Its underseat storage fits two full-face helmets, and it also has a glove box and top case.
