Honda Shadow Phantom VT750C2A
- Production years
- 2009–2010
- Brand
- Honda
1 / 6
HONDA Shadow Phantom VT750C2A (2009-2010)
Selected year: 2010
Technical specifications
- Engine capacity
- 745 cm³
- Wet weight
- 249 kg
- Seat height
- 653 mm
Overview
The Honda Shadow Phantom VT750C2A is a cruiser from the Shadow family, produced for 2010. Its 745 cm³ liquid-cooled 52-degree V-twin has a single overhead camshaft and three valves per cylinder; it weighs 249 kg.
The 653 mm seat is low, which can make it easier to get both feet down at a stop. At 249 kg, the bike takes more effort to maneuver at low speeds, while the shaft final drive means there is no chain to clean or adjust; the rear shocks also have five-position spring preload adjustment.
Specifications
Engine
Engine
- Engine capacity
- 745 cm³
- Compression ratio
- 9.6:1
- Stroke
- 79 mm
Performance and transmission
Performance and transmission
- Clutch
- Wet multi-plate, manual
- Final drive
- Shaft
Dimensions and weight
Dimensions and weight
- Fuel capacity
- 15.1 L
- Seat height
- 653 mm
- Wet weight
- 249 kg
- Wheelbase
- 1,638 mm
Chassis and suspension
Chassis and suspension
- Frame
- Steel
Brakes and wheels
Brakes and wheels
- Front tyre
- 120/90-17
- Rear brakes
- Drum
- Rear tyre
- 160/80-15
Pros and cons
Advantages
Low seat
The 653 mm seat height can make stopping and supporting the bike easier for riders who prefer a low perch.
Shaft final drive
The shaft drive avoids routine chain cleaning and adjustment.
Adjustable rear preload
Five preload positions let riders adjust the rear suspension for different loads.
Things to consider
Heavy at low speed
At 249 kg, maneuvering in tight spaces or at walking pace takes more effort.
Rear drum brake
The rear uses a drum brake rather than a disc.
Rider fit
Rider fit calculator
Calculated in your browser
Don't know it? Leave this empty and we'll estimate it from your height.
Estimated from your height: 79 cm
How to measure
Stand barefoot with your back to a wall. Hold a book firmly between your legs, then measure from the floor to the top edge of the book.
Estimated ground reach
Both feet likely flat
You should have a stable stance at a stop, although seat width and suspension setup still matter.
Seat height
653 mm
Approx. loaded height
623 mm
Estimate assumes about 30 mm of suspension sag. Seat width, footwear, luggage and suspension settings can change real reach. Always sit on the motorcycle before buying.
Fuel range calculator
Enter your expected fuel consumption to estimate the distance on a full tank, with or without a fuel reserve.
Tank 15.1 L at 5.5 L/100 km
Lower consumption = longer range.
Estimated range
275 km
With 10% reserve
247 km
This is a planning estimate, not a measured result. Speed, route, weather, load and riding style can change real consumption.
FAQ
What engine does the 2010 Honda Shadow Phantom VT750C2A have?
It has a 745 cm³ liquid-cooled 52-degree V-twin with a single overhead camshaft and three valves per cylinder.
How tall is the seat on the 2010 Honda Shadow Phantom VT750C2A?
The seat height is 653 mm.
Does the 2010 Honda Shadow Phantom VT750C2A have a chain drive?
No, it uses shaft final drive.
What brakes does the 2010 Honda Shadow Phantom VT750C2A use?
It has a 296 mm front disc with a two-piston caliper and a rear drum brake.
